NexBlue Point 7.4kW EV Charger – Black (Model NB2670A-BLACK)
Future-ready home charging with premium safety, seamless app control, and OTA updates.
The NexBlue Point 7.4kW EV Charger is a powerful, wall-mounted smart charger designed to meet the latest UK regulations, including full OZEV approval and integrated PEN fault protection. Ideal for residential use, it delivers up to 7.4kW single-phase charging and supports all grid types (TN-C-S, TN-C, TN-S, and TT).
With support for dynamic load balancing and solar surplus charging (via NexBlue Zen), it’s engineered for energy efficiency, flexibility, and ease of use. Installation is quick, configuration is intuitive, and updates are automatic over Wi-Fi, Bluetooth, or 4G eSIM.
Key Features
-
7.4kW smart AC charging (1-phase)
-
Type 2 untethered socket (bring your own cable)
-
Integrated PEN fault and anti-tamper protection
-
Full compliance with UK Smart Charging Regulations 2021
-
OZEV approved – eligible for grant schemes
-
Compatible with all UK grid systems: TN-C-S, TN-C, TN-S, TT
-
Built-in energy meter and multicolour LED status ring
-
Dynamic Load Balancing & solar integration (via NexBlue Zen)
-
App-controlled with advanced scheduling and usage tracking
-
Multiple start options: RFID, NFC, App, Portal, Plug & Play
-
3-year warranty and CE-certified (SGS and TUV)
Smart Features
-
Dynamic Load Balancing – Automatically adjusts output to avoid overloading
-
EcoPilot Mode – Automatically schedules the cheapest energy rates
-
Scheduled Charging – Set charging sessions for off-peak hours
-
OTA Updates – Automatically receive firmware updates via Wi-Fi, BLE, or 4G eSIM
-
NexBlue App & Portal – Control charging, view history, and share access with family
What’s Included
-
NexBlue Point EV Charger (Black, NB2670A-BLACK)
-
Wall-mount back plate
-
Installation screws and guides
-
Quick start setup leaflet
-
Access to the myNexBlue app and NexBlue web portal
-
3-Year Manufacturer Warranty
Technical Specifications
Brand: NexBlue
Model: NB2670A-BLACK
Range: Point
Product Type: EV Charger
Charging Power: 1.4 – 7.4kW (Single Phase)
Connection Type: Type 2 Socket
Charging Mode: Mode 3
App Control: Yes (myNexBlue App)
Remote Charging Schedule: Yes
Start Modes: Plug & Play / RFID / NFC / App / Portal
PEN Fault Protection: Integrated – BS 7671 Compliant
Anti-Tamper Protection: Yes
Load Management: Yes – via NexBlue Zen
EcoPilot Scheduling: Yes – based on lowest-cost tariffs
Energy Meter: Built-in (±2% Accuracy)
Wi-Fi: 2.4GHz 802.11b/g/n
Bluetooth: BLE 4.2
4G Connectivity: LTE Cat M1 / 2G / GPRS with built-in eSIM
OCPP: Local OCPP 1.6-J
LED Indicator: Multicolour status ring
IP Rating: IP54
IK Rating: IK08
UV Resistant: Yes
Mounting: Wall-mounted
Dimensions (HxWxD): 235 x 230 x 130 mm
Weight: 1.8 kg
Operating Temperature: -30°C to +50°C
Input Voltage: 230V ±10%
Rated Current: 6A to 32A
Warranty: 3 Years
OZEV Approved: Yes
CE Certified: Yes – SGS & TUV
